Altronix AL400UL Proprietary Power Supply
Manufacturer: Altronix Corporation
Mfr. Part: AL1024ULACMCB
Wall Mount, Enclosure - 120 V AC Input - 24 V DC Output
About This Product
Overview
Model AL1024ULACMCB converts a 115VAC 60Hz input into eight (8) independently controlled 24VDC Class 2 Rated power limited PTC protected Fail-Safe and/or Fail-Secure outputs with a total of 10 amp continuous supply current. The fire alarm disconnect feature enables emergency egress in the event the fire alarm system is activated. It is individually selectable for any or all of the eight (8) outputs. Model AL1024ULACM is a fuse protected version of this unit.
- Access Power Controller with power supply.
- 8 PTC Class 2 power-limited outputs provide 24VDC @ 10A.
- Outputs are individually selectable for Fail-Safe or Fail-Secure operation.
- Fire alarm disconnect is selectable by output.
- UL and cUL listed.
Quick Specifications
- Product Model
- AL1024ULACMCB
- Packaged Quantity
- 1
- Product Type
- Proprietary Power Supply
- Protection Type
- Short Circuit Thermal Overload
- Input Voltage
- 120 V AC
- Output Voltage
- 24 V DC
- Output Voltage Detail
- 24 V DC @ 10 A
- Output Current
- 10 A
