Altronix 8-Port Managed 802.3bt Midspan Injecto
Manufacturer: Altronix Corporation
Mfr. Part: NETWAY8BT
120 V AC, 230 V AC Input - 8 x PoE Input Port(s) - 8 x PoE Output Port(s) - 480 W - 1U
About This Product
Overview
Altronix NetWay8BT is a 8-port networked Managed Midspan in a 1U rack enclosure. It provides PoE/PoE+/Hi PoE up to 90W (802.3bt compliant) power per port, 480W total max. and passes data at 10/100/1000 Mbps at distances up to 100m. Features also include an integral battery charger for applications requiring backup and embed- ded LINQ™ Technology to monitor, control, and report power and diagnostics from anywhere over the network.
- IEEE 802.3af (15W), IEEE 802.3at (30W) and IEEE802.3bt compliant.
- 90W maximum power per port (480W total power).
- Eight (8) ports for cameras/edge devices over ethernet.
- Local and/or remote access to critical information via LAN/WAN.
- Event Log tracks history.
- Built-in IP networked management allows for remote camera reset and monitoring.
- Speed: 10/100/1000 Mbps.
- Port status LEDs.
- Auto detection and protection of legacy non-PoE cameras/devices.
- Real-time power diagnostics with e-mail and Windows Dashboard Alert notifications
Quick Specifications
- Product Model
- NETWAY8BT
- Product Type
- PoE Injector
- Input Voltage
- 120 V AC 230 V AC
- Maximum Input Current
- 5.50 A
- Maximum Output Power
- 480 W
- Input Ports
- 8 x PoE
- Output Ports
- 8 x PoE
- Form Factor
- Rack Mountable
