Altronix NetWay8G PoE Injector
Manufacturer: Altronix Corporation
Mfr. Part: NETWAY8G
120 V AC, 230 V AC Input - 55 V DC Output - 1 x 10/100/1000Base-T Input Port(s) - 8 x 10/100/1000Base-T Output Port(s) - 240 W - 1U
About This Product
Overview
Altronix NetWay8G is an 8 port networked Managed Midspan in a 1U rack enclosure. It provides PoE/PoE+ (up to 30W) power per port, and passes data at 10/100/1000 mbps at distances up to 100m. Ethernet network distance can be extended up to 1000m using Altronix NetwayXT or NetwayXTX repeaters or Altronix Pace series Ethernet extenders. The unit incorporates a battery charger for installations requiring battery backup. Typical applications include Ethernet cameras and edge devices. PoE power management and monitoring is controlled through the unit's LINQ™ - based technology networked management port.
- IEEE 802.3af (15W) and IEEE 802.3at (30W) compliant.
- Eight (8) ports for cameras/edge devices over ethernet.
- Speed: 10/100/1000 Mbps.
- 30W maximum power per port.
- Port status LEDs.
- Auto detection and protection of legacy non-PoE cameras/devices.
- Real-time power diagnostics with e-mail and Windows Dashboard Alert notifications.
- Local and/or remote access to critical information via LAN/WAN.
- Event Log tracks history.
- Built-in IP networked management allows for remote camera reset and monitoring.
- Built-in battery charger.
- UL Listed in the U.S. and Canada.
- CE Approved.
- Lifetime Warranty / Made in the U.S.A.
Quick Specifications
- Product Line
- NetWay
- Product Model
- NetWay8G
- Product Type
- PoE Injector
- Protection Type
- Short Circuit
- Input Voltage
- 120 V AC 230 V AC
- Maximum Output Voltage
- 55 V DC
- Minimum Input Current
- 1.80 A
- Maximum Input Current
- 3 A
