ComNet CNFE1M1A/4 Transceiver/Media Converter
Network (RJ-45) - 1x PoE+ (RJ-45) Ports - 1 x SC Ports - Multi-mode - 1310 nm, 1550 nm Fiber - Fast Ethernet - 10/100Base-TX, 100Base-FX - 3 km - Power Supply - Internal
About This Product
Overview
The ComNet™ Ethernet internal mounted media converters are designed to transmit and receive 10/100 Mbps data over multimode or single mode optical fiber. The electrical interface will Auto-Negotiate to a 10 Mbps, or 100 Mbps Ethernet rate without any adjustments. The optical interface operates at a 100 Mbps Ethernet rate. These media converters are environmentally hardened to operate in extreme temperatures. LED indicators are provided for rapidly ascertaining equipment operating status. The CNFE1/X do not have a metal enclosure and are designed to be incorporated within a device.
- Supports optical fiber cable for durable performance, minimal signal loss, and fast data transfers to greater distances
- Expand your network capacity and fulfill requirement with this 2 transceiver/media converter
- With 10/100Base-TX technology get up to 100Mbps data transfer rate over twisted pair cable
- Takes minimal energy and effort to get installed internally
Quick Specifications
- Product Series
- CNFE1(M,S)/(X)
- Product Model
- CNFE1M1A/4
- Product Type
- Transceiver/Media Converter
- Total Number of Ports
- 2
- Network (RJ-45)
- Yes
- DVI
- No
- USB
- No
- Management Port
- No
