Finisar 100GBASE-LR4 10km Gen2 CFP2 Optical Transceiver
Manufacturer: Finisar Corporation
Mfr. Part: FTLC1151SDPL
For Data Networking, Optical Network - 1 x LC Duplex 100GBase-LR4 Network - Optical Fiber - Single-mode - 100 Gigabit Ethernet - 100GBase-LR4 - Hot-pluggable
About This Product
Overview
Finisar's FTLC1151SDPL QSFP28 transceiver modules are designed for use in 100 Gigabit Ethernet and 4x28G OTN client interfaces over single mode fiber. They are compliant with the QSFP28 MSA, IEEE 802.3ba 100GBASE-LR4 and OTU4 4I1- 9D1F requirements specified in ITU-T Recommendations G.959.1/G.709 and Supplement 39 (G.sup39). Digital diagnostic functions are available via the I2C interface, as specified by the QSFP28 MSA and Finisar Application Note AN-2152 5. The transceiver is RoHS-6 compliant per Directive 2011/65/EC and Finisar Application Note AN-2038.
- Hot-pluggable QSFP28 form factor
- Supports 103.1Gb/s and 112Gb/s aggregate bit rates
- Power dissipation < 3.5W
- RoHS-6 compliant
- Commercial case temperature range of 0°C to 70°C
- Single 3.3V power supply
- Maximum link length of 10km on Single Mode Fiber (SMF)
- 4x28Gb/s DFB-based LAN-WDM transmitter
- 4x28G retimed electrical interface
- Duplex LC receptacles
Quick Specifications
- Product Model
- FTLC1151SDPL
- Product Type
- CFP2
- Application/Usage
- Data Networking Optical Network
- Total Number of Ports
- 1
- Connector Type
- LC
- Interfaces/Ports Details
- 1 x LC Duplex 100GBase-LR4 Network
- Media Type Supported
- Optical Fiber
- Fiber Mode Supported
- Single-mode
