Finisar SFP+ Module
Manufacturer: Finisar Corporation
Mfr. Part: FTLF8536W4BTV
For Optical Network, Data Networking - 1 x Duplex LC 100GBase-SR Network - Optical Fiber - 50/125 µm - 850 nm, 840 nm, 860 nm Wavelength - Multi-mode - 100 Gigabit Ethernet - 100GBase-SR - 25.78 Gbit/s - 0.10 km Maximum Distance - Hot-pluggable
About This Product
Overview
Finisar's FTLF8536W4BTV SFP+ transceivers are designed for use in 25Gb/s data rate over multimode fiber. They are compliant to IEEE802.3by, SFF-8472 Rev 12.2b and SFF-8402g , and compatible with SFF-8432a and applicable portions of SFF-8431 Rev. 4.1c . The transceiver is RoHS compliant and per Directive 2011/65/EUd . See Finisar Application Note AN-2038 for more details
- Up to 25.78 Gb/s bi-directional data links
- Hot-pluggable SFP+ footprint
- Built-in digital diagnostic functions
- 850nm Oxide VCSEL laser transmitter
- Duplex LC connector
- RoHS compliant
- 100m over M5F MMF (50/125 um OM4)
- 70m over M5E MMF (50/125um OM3)
- 20m on MMF (50/125?m OM2)
- Metal enclosure, for lower EMI
- 1.2W maximum power consumption
- Single 3.3V power supply
- Operating temperature range: -40°C to 85°C
Quick Specifications
- Product Type
- SFP+
- Application/Usage
- Optical Network Data Networking
- Total Number of Ports
- 1
- Connector Type
- LC
- Interfaces/Ports Details
- 1 x Duplex LC 100GBase-SR Network
- Media Type Supported
- Optical Fiber
- Fiber Optic Cable Core/Cladding Specification
- 50/125 µm
- Fiber Optic Cable Wavelength
- 850 nm 840 nm 860 nm
