Finisar FTLX1475D3BCV SFP+ Module
For Data Networking, Optical Network - 1 x LC Duplex Fiber Channel Network - Optical Fiber - Single-mode - 10 Gigabit Ethernet - Fiber Channel, 10GBase-LR/LW - Hot-pluggable
About This Product
Overview
Finisar's FTLX1475D3BCV 10Gb/s Enhanced Small Form Factor Pluggable SFP+ transceivers are designed for use in 1-Gigabit and 10-Gigabit Ethernet links up to 10km over Single Mode Fiber. They are compliant with SFF-8431, SFF-8432 and IEEE 802.3ae 10GBASE-LR/LW and 10G Fibre Channel 1200-SM-LL-L. This product is for applications specifically designed for 10G SFP+ ports and 1G/10G SFP+ ports and not native 1G SFP ports. Digital diagnostics monitoring is available via a 2-wire serial interface, as specified in SFF-8472. The FTLX1475D3BCV employs a limiting receiver. The transceiver is compliant per the RoHS Directive 2011/65/EU. See Finisar Application Note AN-2038 for more details.
- Hot-pluggable SFP+ footprint
- Supports rate selectable 1.25 Gb/s and 9.95 to 10.5 Gb/s bit rates
- Power dissipation < 1W
- RoHS-6 compliant (lead-free)
- Single 3.3V power supply
- Maximum link length of 10km
- Uncooled 1310nm DFB laser
- Receiver limiting electrical interface
- Duplex LC connector
- Built-in digital diagnostic functions
- Commercial temperature range: -5°C to 70°C
Quick Specifications
- Product Model
- FTLX1475D3BCV
- Product Type
- SFP+
- Application/Usage
- Data Networking Optical Network
- Total Number of Ports
- 1
- Connector Type
- LC
- Interfaces/Ports Details
- 1 x LC Duplex Fiber Channel Network
- Media Type Supported
- Optical Fiber
- Fiber Mode Supported
- Single-mode
