Juniper EX4100-H-12MP-DC-T Ethernet Switch
12 Ports - Manageable - 2.5 Gigabit Ethernet, 10 Gigabit Ethernet - 10/100/1000Base-T, 2.5GBase-T, 10GBase-X - 3 Layer Supported - Modular - 360 W PoE Budget - Twisted Pair, Optical Fiber - PoE Ports - Wall Mountable, Rail-mountable, DIN Rail Mountable, Magnetic Mount, Compact, Standalone - Lifetime Limited Warranty - TAA Compliant
About This Product
Overview
The Juniper Networks® EX4100-H ruggedized line of Ethernet switches offers a fanless, secure, reliable, cloud-native portfolio delivering high-quality network services in extreme conditions, including freezing and scorching temperatures, with an extended operating temperature range for extreme indoor and outdoor applications. EX4100-H switches are ideal for use cases where extreme temperatures, potential physical impact, and vibrations are common.
EX4100-H switches combine the simplicity of the cloud, the power of Mist AI™ , and a robust, high-performance hardware foundation to deliver a differentiated approach to access switching in the cloud, mobile, and IoT era. With Juniper® Mist™ Wired Assurance, you can effortlessly onboard, configure, and manage EX4100-H switches from the cloud. This simplifies operations and improves visibility and troubleshooting, ensuring optimal experiences for connected devices.
Key features of EX4100-H Line include:
- Cloud-native, AI-Native switches with Wired Assurance and Marvis VNA
- Fanless with an extended operating temperature range of -40°C to +75°C for harsh environments
- Ruggedized, compact form factor for easy installation in tight spaces
- Compliant to IP30 and supports a relative humidity range of 5% to 95%, ensuring noncondensing operation
- Meets many industrial certifications, making it suitable for use in a wide range of applications that need high tolerances for constant vibrations, shocks, and electromagnetic immunity
- Dry contact alarm: two alarms in and one alarm out to signal external sensors
- Dual redundant PSUs: two AC PSUs or two DC PSUs or one AC and one DC PSU
- Ethernet VPN-Virtual Extensible LAN (EVPN-VXLAN) to the access layer
- Standards-based microsegmentation using group-based policies (GBPs)
- Switch-to-switch encryption using Media Access Control Security (MACsec) AES256
- IEEE 802.3bz Multigigabit
- IEEE 802.3bt Power over Ethernet Plus (PoE++)
- Flow-based telemetry to monitor traffic flows for anomaly detection and the ability to measure packet delays and report drop reasons
- Precision Time Protocol-Transparent Clock
- 10-member Virtual Chassis support
The EX4100-H Family consists of the following models:
- The EX4100-H-12MP, offering 4 x 100MB/1GbE/2.5GbE and 8 x 10 MB/100 MB/1GbE PoE++ access ports, delivers up to 90 W per port with a total PoE budget of 360 W using two power supplies.
- Ethernet Switch supports increased network bandwidth availability through data switching
- Cascade connections to other network devices through the uplink port to extend a local area network topology
- Stack port supports data communication between stacked devices within a network configuration
- Features 12 networking ports to establish a local wired network or extend connectivity within an existing layout
- Built?in power supply supports internal components by providing required operating voltage
- Layer 3 support allows routing functionality that supports network scalability through structured traffic handling
- Wall?mountable design supports installation on vertical surfaces to help organize placement and cable routing
- Management capability enables control over network setup and configuration according to operational requirements
- 2.5 Gigabit Ethernet Ethernet technology supports network communication and connectivity using a reliable and straightforward connection method
- Twisted pair cable support enables cost?efficient network connections for data transmission across distances
Quick Specifications
- Product Model
- EX4100-H-12MP-DC
- Product Type
- Ethernet Switch
- Features
- Fanless
- Total Number of Network Ports
- 12
- Uplink Port
- Yes
- Modular
- Yes
- Stack Port
- Yes
- Port/Expansion Slot Details
- 4 x 2.5 Gigabit Ethernet PoE++ 8 x Gigabit Ethernet PoE++ 2 x 1/10GbE SFP+ Fixed Uplink Ports 2 x 1/10GbE SFP+ Ports
