Ortronics Infinium Quantum M4 Splice Cassette, 12 Single Fiber, LC Duplex, SM, OS2
About This Product
Overview
Infinium Quantum Splice Cassettes are available in the Infinium M4 footprint, enabling industry leading performance, fast field termination, and providing cable management within the housing. The Splice Cassettes are designed for use with Single-Mode (OS2) or Multimode (OM4/OM5) Fiber, Houses 12-24 fibers and are available in LC Duplex or LC Quad port configurations.
The 12 fiber cassettes and support fusion splicing of individual fibers, while the 24 fiber cassettes support fusion splicing of ribbon fibers. Heat shrinks, pigtail slack and cable slack are managed within the cassette-eliminating the need for individual splice trays or housings. The design of the cassettes allows easy mounting from either the front or the rear of an enclosure or panel, and individual fibers within the cassette may be accessed without disturbing the other fibers in the housing.
- Supports 12 fibers with LC Duplex ports.
- Enables fast fusion splicing and organized cable management.
- Provides high-performance connectivity for OS2 fiber.
- Utilizes Shuttered Adapters
Quick Specifications
- Product Line
- Infinium
- Product Type
- Splice Cassette
- Color Family
- Blue
- Product Color
- Blue
- Product Material
- Thermoplastic Zirconia
- Height
- 1.1"
- Width
- 3.5"
- Depth
- 4.8"
