Lenovo PM9A3 960 GB Solid State Drive - M.2 22110 Internal - PCI Express NVMe (PCI Express NVMe 4.0 x4) - Read Intensive
Server Device Supported - 1 DWPD - 1752 TB TBW - 5000 MB/s Maximum Read Transfer Rate - 1 Year Warranty
About This Product
Overview
The ThinkSystem PM9A3 Read Intensive NVMe Solid-State Drives (SSDs) are general-purpose yet high-performance family of NVMe SSDs. They are engineered for greater performance and endurance in a cost-effective design, and to support a broader set of workloads.
This product guide provides essential presales information to understand the ThinkSystem PM9A3 Read Intensive NVMe SSDs offerings and their key features, specifications, and compatibility. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the PM9A3 SSDs and consider their use in IT solutions.
- Low cost, read-intensive SSD from Samsung
- Direct PCIe 4.0 x4 connection for each NVMe drive, resulting in up to 8 GBps overall throughput.
- TCG Opal SED drive encryption
- Advanced ECC Engine and End-to-End Data Protection
- Samsung 32 layer V-NAND stacks the vertical NAND layers in three dimensions, solving the cell-to-cell interference that causes data corruption in planar NAND.
- Protect data integrity from unexpected power loss with Samsung's advanced power-loss protection architecture
- Supports Self-Monitoring, Analysis and Reporting Technology (S.M.A.R.T).
Quick Specifications
- Product Series
- PM9A3
- Product Type
- Solid State Drive
- Storage Capacity
- 960 GB
- Maximum Read Transfer Rate
- 5000 MB/s
- Maximum Write Transfer Rate
- 1400 MB/s
- Random 4KB Read
- 550000IOPS
- Random 4KB Write
- 60000IOPS
- Endurance (DWPD)
- 1
