Panduit ISFCH6X04ABL-UG Copper Cable, Industrial
1000 ft Category 6a Network Cable for Network Device, Control Panel - First End: Bare Wire - Second End: Bare Wire - 10 Gbit/s - Shielding - CM, CMX, Riser - 24/7 AWG - Black - 1000
About This Product
Overview
Category 6A 4-pair SF/UTP copper cable shall meet or exceed the IEC 61156-6, ANSI/TIA-568-C.2 Category 6A and ODVA Ethernet/IP standards up to 80 meters. The stranded copper conductors shall be 24/7 and 26/7 AWG with high density polyethylene (HDPE) insulation. The copper conductors shall be twisted in pairs and wrapped with a foam polypropylene tape to form a core. All pairs shall then be surrounded by an overall braided shield and metallic foil and covered with a thermoplastic elastomer (TPE) jacket. The jacket shall be oil, UV, weld splatter, and abrasion resistant for enhanced chemical resistance and mechanical performance. The jacket shall be flame retardant (CMX/CM) for Industrial Ethernet applications. This cable shall support high-flex applications and be rated for panel or on-machine applications where space is shared with 600V high voltage cables.
- Third party tested : Cable has been tested by an independent laboratory and complies with the electrical standard requirements of IEC 61156-6 Category 6A and ANSI/TIA-568-C.2 Category 6A standards
- Reliability : Shielded SF/UTP cable construction protects against environmental elements that can cause electrical performance failures; stranded conductors for high flex applications and ease of installation; cable jacket is oil, sunlight, weld splatter, and abrasion resistant for enhanced chemical resistance and mechanical performance
- High flex applications : Life cycle tested for robotic and c-track use
- 600V on-machine applications : Rated for panel or on-machine applications when the space is shared with 600V high voltage power cables
Quick Specifications
- Product Line
- IndustrialNet
- Packaged Quantity
- 1000
- Product Type
- Network Cable
- Cable Type
- Category 6a
- Cable Length
- 1000 ft
- Connector Type on First End
- Bare Wire
- Connector on First End Details
- Bare Wire
- Connector Type on Second End
- Bare Wire
