PanNet Copper Cable, Cat 6, 23 AWG, UTP, CMP, Green
Manufacturer: PANDUIT CORP
Mfr. Part: PUP6004GR-WLPZ
1000.66 ft Category 6 Network Cable for Network Device - 10 Gbit/s - Unshielded Twisted Pair (UTP) - CMP, Plenum, CMP-LP - 23 AWG - Green
About This Product
Overview
The TX6000™ Cat 6 UTP copper cable is constructed of 23 AWG copper conductors with FEP/polyolefin (CMP) insulation. The copper conductors shall be twisted in pairs, separated by a cross-divider and covered by a low smoke, flame-retardant, plenum-rated, green jacket.
- Third party tested: Cable has been tested as part of the TX6000 U/UTP Copper Cabling System by an independent laboratory and complies with the electrical channel requirements of the following Standard: ANSI/TIA-568.2-D Category 6
- Guaranteed channel performance above the Standards: Industry leading guaranteed channel performance exceeds the TIA/ISO Standards with headroom guaranteed
- Integrated pair divider: Separates pairs for exceptional cable performance
- Reelex™ packaging: Compact carton ensures proper performance and provides quick installation
- Tested beyond the Standards: Cable has been characterized to 650 MHz, 400 MHz above the Standard
- Extended temperature range: Allows operation in 90°C (194°F) ambient environment providing error-free performance in high-density cabinets and large cable bundles running PoE+ or PoE++ applications
- Descending length cable markings: Easy identification of remaining cable reduces installation time and cable scrap
Quick Specifications
- Product Line
- TX6000
- Product Type
- Network Cable
- Cable Type
- Category 6
- Cable Length
- 1000.66 ft
- Cable Shielding Type
- Unshielded Twisted Pair (UTP)
- Connector Type on First End
- Bare Wire
- Connector Type on Second End
- Bare Wire
- Shielding
- No
