PanNet TX6A Vari-MaTriX Copper Cable, Cat 6A, 23 AWG, U/UTP, CMP, Black
Manufacturer: PANDUIT CORP
Mfr. Part: PUP6XHD04BL-G
1000 ft Category 6a Network Cable for Network Device - 10 Gbit/s - CMP, Plenum - 23 AWG - Black, Metallic
About This Product
Overview
The TX6A™ Cat 6A U/UTP Plenum copper cable is constructed of 23 AWG copper conductors with FEP insulation. The copper conductors shall be twisted in pairs. All four pairs shall be surrounded by a metallic alien crosstalk barrier tape and covered by a flame retardant PVC (CMP), Black jacket. Packaged 1000 ft./305m on a reel.
- Headroom warranty: Provides worst-case margins above the industry standard for both electrical and alien crosstalk performance
- High density cable design: Improves fill capacity, cable management, reduces required bend radius and allows efficient use of pathways and spaces
- Extended temperature range: Allows operation in 105°C (221°F) ambient environment providing error-free performance in high-density cabinets and large cable bundles running PoE+ or PoE++ applications
- Highest port density: All testing and headroom based on 48-port/1RU panels
- Descending length cable markings: Easy identification of remaining cable to reduce installation time and cable scrap
Quick Specifications
- Product Line
- TX6A
- Package Type
- Bulk
- Product Type
- Network Cable
- Cable Type
- Category 6a
- Cable Length
- 1000 ft
- Connector Type on First End
- Bare Wire
- Connector Type on Second End
- Bare Wire
- Shielding
- No
