SIIG HDMI 2.0 4K HDR Pattern Generator / Analyzer
Manufacturer: SIIG, Inc
Mfr. Part: CE-H23N11-S1
HDCP Test, EDID Test, Loop Test, Firmware Upgrade-able - Battery Powered
About This Product
Overview
Advanced pattern generator with 5 major functions including full bandwidth HDCP 2.2 support is a versatile HDMI tool for AV installers and system integrators
- Major Functions - HDMI Generator/Analyzer/Receiver (Display), HDCP Test, EDID Test, Loop Test, Firmware upgradeable
- HDMI Signal Generator - Compliant with HDMI 2.0a, HDCP 2.2. 18Gbps video bandwidth
- HDMI Resolution Support - 4K@60Hz YUV 4:4:4 8-bit, 4K@60Hz YUV 4:2:0 16-bit (HDR)
- Finger Tip Control - Built-in 4.3" touch screen, USB mouse and Ethernet to allow users to verify HDMI sources instantly
- Battery Powered - Rechargeable battery for portability. Up to 4 hours operating time at full charge
Quick Specifications
- Product Type
- Testing Device
- Device Function
- Video Testing Video Signal Testing
- HDMI
- Yes
- USB
- Yes
- Audio Line Out
- Yes
- Network (RJ-45)
- Yes
- Number of Network (RJ-45) Ports
- 1
- Media Type Supported
- Twisted Pair
